KM8403001M — 944066040 01
AEG — Microwave
Parts for KM8403001M
W0017871 ASSEMBLY,CONDENSATION,MOTOR,24
$347.00
W0022985 CABLE, SENSOR, OVEN, L=1000
$229.00
W0023180 GRILL GRID, 466X385X22.2MM
W0026274 MOTOR, CONVEYOR, 230V,
$183.00
W0026279 HEATING ELEMENT, UPPER, 230V,1900W
$155.00
W0026281 MAGNETRON
$243.00
W0026282 TRANSFORMER, 230V/50HZ
$447.00
W0026283 MOTOR, STIRRER, 230V
$111.00
W0026285 ASSEMBLY, COOLING FAN, COMPLETE
$121.60
W0026301 FAN STIRRER
$31.95
W0026302 SENSOR, PT500
$68.00
W0026303 HEATING ELEMENT, ROUND, 230V,1650W
$150.00
W0026380 HARNESS, POWER BOARD, XP06<->SIDEKICK
$136.00
W0026427 ADAPTOR DOOR HANDLE BLK
$39.00
W0026428 DOOR HANDLE, ROUND, INOX
$50.00
W0026472 HARNESS USER INTERFACE BOARD X
$34.90
W0026986 GASKET, OVEN DOOR
$62.00
W0027116 GRID, RIGHT
$72.00
W0027117 GRID, LEFT
$72.00
W0027369 HINGE, 7.1KG
$41.20
W0027376 HINGE, 7.1KG
$65.00
W0114339 BUSH, FRONT FRAME
$9.00
W0114583 HEATING ELEMENT, BOTTOM, 1000W
W0147344 BULB, OVEN LAMP, G9,230V,25W
W0017784 MOUNTING PLATE,BACK
$61.80
W0017873 SAFETY,SWITCH,LEFT,L
W0017874 SWITCH SAFETY RIGHT
$50.85
W0022369 THERMOSTAT RED BLK 145.C
W0022555 BOLT TORX B63 5X6
$5.50
W0022556 SCREW TORX 4 X 10 T20
$5.50
W0023126 BOTTOM PLATE
$37.10
W0023165 SCREW MOUNT 4.2MM X 9.5MM
$17.00
W0023181 SUPPORT, HINGE, LEFT
$29.50
W0023182 SUPPORT, HINGE, RIGHT
$29.50
W0023205 CARRIER, USER INTERFACE BOARD, OMEGA
$32.15
W0023209 CLAMP CABLE 15x 16mm
$4.00
W0023211 CABLE HOLDER
$6.00
W0023212 SHIELD, BOTTOM, HEATER
$37.10
W0023274 FUSE RETAINER, COMPLETE, T10AL/230V
$52.00
W0024182 KIT,BUSH,SCREW HANDLE
$19.00
W0026025 KIT,SUPPORT,SPACE COMPENSATOR
$12.40
W0026251 SIDE PANEL, LEFT-RIGHT, 478,6X336,4X30MM
$74.20
W0026255 BACK PANEL, OVEN, 540X339,9X35MM
$74.20
W0026272 FAN WHEEL, CONVECTION FAN
$54.00
W0026280 BACK PANEL CONVECTION FAN
$98.90
W0026284 SENSOR, MAGNETRON, NTC
$68.00
W0026286 SHIELD, CONVECTION FAN
$17.60
W0026287 DOOR GLASS, 474X244MM
$147.00
W0026288 FRONT FRAME
$91.45
W0026290 BEARING, STIRRER
$35.00
W0026291 RETAINER MOTOR
$14.30
W0026292 COVER, MICA
W0026296 SUPPORT, CONNECTION BOX
$12.40
W0026297 WASHER AXLE 21/11MM
$14.50
W0026300 DIODE, HV
W0026337 CONNECTION BOX, WITH, CABLE, 3X1,5
$77.00
W0026385 NUT, CONVECTION FAN, M6
$6.00
W0026395 GASKET, ROUND, 892,5MM
$42.00
W0026474 HARNESS POWER BOARD DOOR SWITC
$22.25
W0026490 FRONT GLASS, STAINLESS, 591,5X331MM
$373.00
W0026517 TOUCH CONTROL, PANEL
$225.00
W0026532 CONTROL PANEL, 60CM, VCU
$179.00
W0027064 AXLE, STIRRER
$12.25
W0027065 ASSEMBLY INNER DOOR
$211.90
W0027067 HARNESS POWER BOARD MAGNETRON
$71.70
W0027085 GLASS HOLDER, L
$81.00
W0027086 GLASS HOLDER, R
$81.00
W0027100 MOUNTING SET FIXING
$30.00
W0027123 DOOR, TRIM, TOP
$81.00
W0027124 RING, NUT
$11.00
W0027159 GASKET, DOOR, MICROWAVE OVENS
$56.00
W0027169 TAPE, DRIP PROTECTION, FRONT GLASS
$77.00
W0027170 DOOR GLASS 474X244MM
$147.00
W0027232 PIVOT, SIDE, GRID
$18.00
W0027365 COVER TOP
$124.90
W0027368 HINGE WITHOUT SPRING 7.1KG
$61.45
W0028981 CONFIGURED ELECTRONIC USER PCB
$583.00
W0077100 HOLDER,SIDE,GRID,4MM PIN
$35.00
W0103137 LOCKING SPRING. 9MM
W0103177 FILTER, VOLTAGE
W0105621 CLIP.FIXING.ELECTRONIC.I=22.9M
W0106497 BOLT TORX B63 5X9 5 T20
W0114513 POWER BOARD CONFIGURED OVC3000
W0114542 DISH BAKING
W0134348 BOARD INTERFACE VCU UNPROGRAMD
$208.00
W0134350 NUT, HEATING ELEMENT, UPPER,M4
$5.50
W0134463 DOOR, FRAME
W0147316 BRACKET, HINGE, LEFT
$37.10
W0147317 BRACKET, HINGE, RIGHT
$49.45
W0147402 HINGE 7.1KG LONG
$44.00
W0274457 CAP NUT,M6
$29.70
W0375332 CAPACITOR, 1,05MF,230V
$58.00
