ESAM6900.M — 0132219001
DELONGHI — Coffee Machine
Parts for ESAM6900.M
W0276925 SWITCH
$24.30
W0276940 O-RING (D=6.75 T=1.78)
$11.70
W0276942 MICROSWITCH (250V 85°)
$26.00
W0276944 O-RING (D=9.25 T=1.78)
$12.85
W0276945 O-RING (D=6.07 T=1.78)
$8.59
W0276947 DELONGHI COFFEE MACHINE FROTHER
$20.00
W0276958 SCREW (3.5X12)
$11.70
W0276963 FINGER STOP COVER
$12.40
W0276969 STOPPER
$11.70
W0276970 VALVE
$11.70
W0276971 SPRING
$12.00
W0276972 DELONGHI COFFEE MACHINE FILTER O-RING
$12.00
W0276980 MICROSWITCH
$27.00
W0276981 MOTOR WITH PULLEY (ECM 230V)
$89.80
W0276982 HALL SENSOR (L620)
$16.92
W0276991 TUBE WITH 2 BUSHES (L97)
$12.60
W0276993 TUBE WITH 2 BUSHES (L270)
$23.30
W0276995 O-RING (D=3.85 T=2)
$12.00
W0276999 PUMP PROTECTOR
$24.80
W0277010 CLIP (WIRE 1,2 AISI302)
W0277013 MOTOR BELT
$14.00
W0277014 SCRAPER BRUSH WITH BRISTLES
$12.80
W0277015 GREASE TUBE (5GR VERKOFOOD)
$22.90
W0277073 HOSE COUPLING COVER
$11.70
W0277074 TANK GASKET
$13.00
W0277075 WATER TANK FILTER
$11.70
W0277076 SPRING
$11.70
W0277082 RUBBER FOOT PAD
$5.00
W0277083 TOOTHED BELT
$14.00
W0277098 GRINDER BELLOW GASKET
$13.00
W0277100 FILTER (D.40X2.3 TAI-FENG)
$21.50
W0277114 TUBE WITH 2 BUSHES (L150)
$12.10
W0277128 RIGHT ANGLE CONNECTION
$14.00
W0277162 TERMINAL BOARD
W0277212 DELONGHI COFFEE MACHINE PUMP (ULKA 230V 48W)
$37.95
W0277223 SENSOR (NTC L400)
$16.50
W0277240 PORTABLE DIGITAL THERMOMETER, -50 +150°C
$88.90
W0277707 TUBE (L350)
$12.20
W0277735 VALVE
$6.60
W0277750 SUPPORT
$12.30
W0277754 SILICONE HOSE (DI=4 L=270)
$12.80
W0277830 FIXING BRACKET (TCO)
$13.00
W0277831 SENSOR BRACKET
$13.00
W0277854 O-RING
$12.10
W0277879 DOUBLE CONNECTION
$11.70
W0277892 STEAM NOZZLE
$14.08
W0277914 O-RING (D6.07 T1.78)
$12.20
W0277982 MIXING MAGNETIC PADDLE
$12.10
W0278054 COUPLING RUBBER PAD SEAL
$23.50
W0278070 NUT
$12.00
W0278071 BRASS BUSH
W0278073 RING
$11.90
W0278119 MOTOR BOARD (ECM 230V)
$18.00
W0295783 LEVER
$11.70
W0296740 INFUSER
$43.00
W0313562 SAFETY THERMOSTAT (13.5A 318°)
$28.00
.jpg)
W0315270 DELONGHI COFFEE MACHINE COFFEE DREGS CONTAINER
$15.08
W0317798 HOOK
$12.50
W0318028 DRAIN HOSE (90°)
$14.00
W0319778 TUBE WITH NUT AND 1 BUSH (L335)
$16.30
W0319891 DELONGHI SOLENOID VALVE KIT 2 WAY
$38.00
W0323782 SOLENOID VALVE SUPPORT (2V)
$12.80
W0323783 SOLENOID VALVE SUPPORT (3V)
$29.00
W0325513 CARAFE COUPLING
$19.00
.jpg)
W0326096 DELONGHI HOT WATER SPOUT PIPETTE
W0273641 SLIDER
$16.00
W0273642 TRANSMISSION ASSEMBLY (CHIAPHUA 230V)
$95.30
W0277861 SEE TECNICAL INFORMATION
W0278072 CONNECTION
W0294266 COFFEE BEANS COVER
$33.00
W0307707 STOPPER
$12.00
W0311588 WIRING FOR FLOWMETER (L630)
W0311607 TCO WITH WIRING
W0311608 TCO WITH WIRING
W0311644 CABLING WITH FUSE (1.25 A)
W0312478 MICROSWITCH (10A/ 250V/ 125°)
$13.60
W0313052 MOTOR BOARD
$65.00
W0313062 POWER BOARD (SW1.1 230V)
$69.60
W0313066 NTC PROBE (L500)
$18.00
W0313147 SOLENOID VALVE
$27.30
W0313303 FLOWMETER
$17.00
W0313587 REED SENSOR
$16.60
W0314929 GRINDING ADJUSTMENT KNOB
$12.00
W0314934 BLACK REAR PANEL CAP
W0314944 REAR PANEL
$30.20
W0314984 SCUFF-PROOF RUBBER PAD
$13.00
W0314992 PUMP SUPPORT
$23.30
W0314993 A T CONNECTION (PRES BLOCK)
W0315014 SHAPE FOR TUBE
W0315029 FLOWMETER TUBE GUIDE
W0315031 SUPPORT
$87.90
W0315218 SWITCH HOLDER
W0315262 CONTROL BOARD BOX
W0315263 CUP HOLDER TRAY
$21.40
W0315264 LEAK DUCT
W0315265 FRAME
$26.90
W0315266 EXPANSION CHAMBER COVER
$12.50
W0315267 FLOAT
$11.70
W0315268 SOLENOID VALVE A T CONNECTION
$11.70
W0315269 REED SUPPORT
W0315303 COUPLING MICRO SUPPORT (IFD)
W0315312 FROTHER NICHE
$24.00
W0315313 WATER INTAKE TUBE
$11.70
W0315359 MOTOR COVER
$13.00
W0315360 MOTOR SUPPORT
$13.60
W0315391 WATER TANK COVER
$15.60
W0315413 CAM
W0315459 GRINDER PANEL
W0315515 TANK PRESENCE CAM
$13.00
W0317616 CONNECTION
$11.70
W0317791 FILTER
$12.00
W0317792 PISTON
$26.80
W0317795 SUPPORT
$11.90
W0317796 BUSH
$11.70
W0317797 BUSH
$11.70
W0317857 RUNNER FRAME
$12.80
W0317886 SILICONE HOSE (DI=4 L=200)
$12.10
W0317981 PIN
$11.70
W0317983 RUBBER PAD
$11.70
W0318015 MEASURING SPOON
$11.70
W0318077 COVER
$12.00
W0319631 TUBE WITH 2 BUSHES (L180)
$12.20
W0319661 COFFEE BEANS TANK WITH RUBBER PADS
$14.10
W0319686 GROUND COFFEE COVER
$31.30
W0319687 COVER WITH CUP WARMER
$94.40
W0319688 RIGHT SIDE
$39.90
W0319689 LEFT SIDE
$35.80
W0319690 MOTOR HOUSING BASE WITH RUBBER PADS
$16.70
W0319710 MOTOR
$18.00
W0319723 DISPLAY BOARD
$295.00
W0319732 TUBE WITH 2 BUSHES (L90)
$13.30
W0319733 WATER TANK FRONT PIECE
$24.10
W0319777 TUBE WITH NUT AND 1 BUSH (L135)
$14.00
W0319909 TUBE WITH 2 BUSHES (L500)
$14.70
W0319929 GENERATOR (R1200W 230V)
$44.30
W0319963 FLOW REGULATOR
$19.00
W0323288 SPRING
W0323289 SPRING
$11.70
W0323457 SPRING
$11.70
W0323458 SPRING
$11.70
W0323459 PIN
W0323460 BRACKET
$11.70
W0323462 SPRING
$11.70
W0323463 TCO BRACKET
W0323465 BRACKET
$11.70
W0323781 POD SUPPORT
$14.30
W0323872 BRACKET
$21.20
W0324202 CUP HOLDER
$82.40
W0325365 MECHANICAL VALVE (ESAM)
$137.50
W0325429 SAFETY VALVE
$14.50
W0325509 DOOR ASSEMBLY
$55.70
W0325601 CONTROL PANEL FRONT PIECE
W0325655 GRINDER ASSEMBLY (3D-DL 230V)
$71.00
W0326029 WATER TANK
$24.40
W0327150 CLIP CLAMP
$12.00
