KSE88HRA — 950001070 00
KELVINATOR — Air-Conditioner
Parts for KSE88HRA
W0014468 BLADE FAN ASSY CROSS FLOW
.JPG)
W0014469 HOLDER BEARING
$7.30
.JPG)
W0014474 MOTOR FAN INDOOR
W0067849 MOTOR LOUVRE
W0069693 MOTOR FAN OUTDOOR
W0069699 BOARD MAIN OUTDOOR
W0094784 BOARD MAIN INDOOR
W0096046 BOARD DISPLAY INDOOR
W0103211 HOSE DRAIN
W0014361 COVER TEMP SENSOR
$5.50
W0014363 CAPAC 3.5UF 450V 2 PIN SOLDER
$7.80
W0014372 CLAMP CAPACITOR
$4.00
W0014446 GUARD. FAN KSE88CRA
$29.70
W0014451 INDICATOR HOLDER ESE24CRB
$6.60
W0014467 LEFT CONNECTOR LOUVRE MSE30CR
$5.50
W0014470 COVER CHASSIS REAR LH
$11.00
W0014471 BACK COVER FOR CHASSIS, RIGHT
$11.00
W0014472 BRACKET FAN MOTOR INDOOR
$18.35
W0014473 FILTER AIR
W0014475 PAN DRAIN
$24.90
W0014478 FUSE
W0015662 RELAY CONTACTOR
$69.90
W0015695 SENSOR TEMP INDOOR
W0016778 VALVE 4-WAY
$120.00
W0017337 WIRE JOINT FOR MULTIPLEXER
$5.50
W0019552 DISPLAY BOARD ENCLOSURE
$27.50
W0019660 CHASSIS
$132.00
W0068066 CLAMP TEMP SENSOR ESG21HRIA
W0068317 CLAMP
W0068318 CLAMP NET OUTDOOR
W0068324 WASHER FOR WIRE JOINT ESD09HRA
W0068697 UNDERLAY REAR NET MSE30CR
W0068700 CLAMP WIRING
W0069028 CAPAC 55UF 440V 4PIN COMPRESS
W0069296 HANDLE SMALL
$10.00
W0069301 PANEL FRONT RIGHT
$49.50
W0069524 E-PARTS BOX ESE24CRB
$80.30
W0069577 EVAPORATOR ASSY
W0069590 BUSH (LARGE) MSE30CR
W0069627 WATERPROOF BOARD ESE24CRB
W0069660 SCREW CAP MSE30CR
W0069661 DOWN CLAP FOR PANEL FRAME
$4.00
W0069662 CAP UPPER FRAME
$4.00
W0069665 LEFT MED CONNECTOR LOUVRE MSE3
W0069666 LOUVRE SMALL MSE30CR
W0069667 LOUVRE BIG
W0069670 MED HOLDER LOUVRE
W0069671 MED LOUVRE MSE30CR
W0069672 BUSH SMALL
$4.00
W0069673 RIGHT HOLDER LOUVRE MSE30CR
W0069674 RIGHTR CONNECTOR MSE30CR
W0069675 RIGHT MED CONNECTOR LOUVRE
W0069676 LEFT HOLDER FOR EVAPORATOR
W0069679 COVER MOTOR
W0069680 MOTOR COVER II MSE30CR
W0069681 FILTER HOLDER
$7.00
W0069682 COVER E-PARTS BOX MSE30CR
W0069683 BLADE FAN
W0069695 VALVE HIGH PRESSURE
$22.00
W0069696 COMPRESSOR
$611.00
W0069697 CAPAC 90UF 400V 4 PIN SOFT STA
$90.00
W0070322 HOLDER REMOTE CONTROLLER MSE3
W0070655 NUT FLARE TLM B02 3/8 9.52MM
$7.70
W0070748 BOARD SOFT STARTER ASSY
W0072244 COPPER NUT TLM-D04 5/8 15.88MM
W0072314 SHROUD FAN
$110.00
W0072315 REAR RIGHT CLAPBOARD MSE30CR
W0072316 INSTALLATION PLATE VALVES MSE
W0072325 TERMINAL BLOCK 8P KSE88CRA
$13.20
W0072501 WIRE JOINT. 5P ESD09HRA
W0072525 EVAPORATOR TEMP SENSOR
W0076552 TRANSFORMER KSE88CRA
W0076553 TRANSFORMER
W0090058 FRAME AIR OUT ASSY
W0090059 LOUVRE HORIZONTAL UP
W0090060 LOUVRE HORIZONTAL DOWN
W0090062 CHASSIS
$132.00
W0090064 E-PARTS BOX MSE30CR
W0090066 CORNER BOARD FOR CHASSIS
W0090070 CABINET FRONT ASSY
$68.20
W0093834 PANEL KSE88HRA
$49.50
W0093892 PLATE INSTALLATION
W0093922 HOLDER. FAN MOTOR KSE88CRA
W0094114 COIL REVERSING VALVE (DUNAN)
$44.00
W0094115 COIL, REVERSING VALVE (SANHUA)
$10.40
W0094116 COIL, REVERSING VALVE (TIANDA)
$10.40
W0094194 CAPILLARY ASSY
$38.50
W0094197 CAPILLARY
$11.00
W0094229 OVERLAY KSE70HRA
$11.00
W0094694 CONNECTING BAR FOR LOUVRE LEFT
W0094711 HANDLE
W0094945 CONDENSER ASSY
$374.00
W0095916 CONDENSER TEMP SENSOR
W0096058 REMOTE CONTROLLER ESE18HRA
W0102653 CLAMP CAPACITOR
W0129523 CAPAC 5UF 45OV 4PIN KPK35CRA
W0132300 VALVE ASSY LOW PRESSURE
