KSV35HRF — 950001552 00
KELVINATOR — Air-Conditioner
Parts for KSV35HRF
W0014946 FILTER CARBON
W0011175 COMPRESSOR KSV35CRE
$499.32
W0012111 EVAPORATOR ASSY
$295.64
W0012196 CONDENSER ASSY
$502.12
W0012299 CLAPBOARD SUB ASSY
$40.00
W0012331 FRAME, WALL MOUNTING
W0012341 COVER, TOP SUB ASSY
$48.76
W0012373 PLATE, LEFT SIDE
$24.00
W0012512 REAR GRILL KSV35CRC
$21.12
W0012537 PANEL FRONT ASSY
$80.00
W0012552 SHIELD, LOWER SUB ASSY ELEC
$32.00
W0012557 SHIELD COVER OF ELECTRIC BOX
$8.80
W0012592 SUPPORT, MOTOR
$32.00
W0012611 SUPPORT, VALVE
$37.60
W0012948 BOARD MAIN ASSY OUTDOOR ELECT
W0012949 BOARD MAIN ASSY OUTDOOR ELECT
$234.96
W0013016 CHASSIS SUB ASSY
$160.00
W0013152 VALVE ASSY, 4-WAY
$328.16
W0013183 CAPILLARY SUB-ASSY
$40.00
W0013514 DRAIN PIPE KSV35CRC
$12.16
W0014086 VALVE CUT-OFF DISCHARGE 1/4
W0014087 VALVE CUT OFF
$40.00
W0014104 VALVE, ELECTRONIC EXPANSION
$84.64
W0014458 FAN, AXIAL FLOW
$43.96
W0014484 FAN, CROSS FLOW
W0014562 BUSH AXILE LH
W0014569 LOUVER, AIR 2
W0014570 LOUVER, AIR 1
$3.20
W0014631 BUSH AXILE
W0014667 CRANK
$4.40
W0015173 FILTER, SUB ASSY
W0015175 FILTER (HEPPA)
W0018884 MOTOR FAN INDOOR KSV26CRE
W0018903 MOTOR FAN OUTDOOR
$172.00
W0018975 MOTOR LOURVE
W0019464 CASE ASSY, REAR
$93.48
W0019465 CASE, FRONT
$55.96
W0019467 PANEL, FRONT ASSY
$48.04
W0019540 BOX, ELECTRIC
$32.00
W0019600 COVER, BOX ELECTRIC 2
$32.00
W0019937 BOARD MAIN INDOOR ASSY ELECT
$232.04
W0020512 COVER, ELECTRIC BOX 1
$8.00
W0020559 GRILL, FRONT
$24.00
W0020659 SUPPORT, EVAPORATOR
$8.00
W0020660 BAR, STAY SUB ASSY
$8.00
W0020774 PLATE, PRESS MOTOR
$24.00
W0020775 HELICOID TONGUE
$5.60
W0020857 RING, BEARING
W0020881 HANDLE BIG
$12.00
W0020950 LOUVER, GUIDE
W0021051 FILTER PC BOARD OUTSIDE
$275.88
W0021242 BOARD MAIN INDOOR
W0021244 BOARD MAIN OUTDOOR KSV35HRE
$304.16
W0021799 BOARD, DISPLAY INDOOR
W0022348 CAPAC CBB61S
$4.36
W0023277 SENSOR TEMPERATURE
$35.24
W0023279 SENSOR TUBE TEMP (20K BLK)
W0023352 CORD POWER KSV26CRC
$26.40
W0024728 TERMINAL BOARD KSV26HRC
$11.92
W0024732 TERMINAL BOARD 4-BIT
$11.92
W0024761 WIRE JUMPER
$16.00
W0024867 MAGNET COIL KSV26NRC-OUD
$56.08
W0024876 COIL REACTOR
$68.52
W0026765 CLAMP, WIRE
$3.20
W0026843 COMPRESSOR GASKET KWH07CRC
$8.00
W0026850 PLUG WATER TRAY
W0096142 SCREW COVER
$3.20
W0096481 PIPE CLAMP KSV26CRC
$3.20
W0102058 REMOTE CONTROL
W0142539 BEARING. O-GASKET SUB ASSY
