KSV62HRA — 950001084 01
KELVINATOR — Air-Conditioner
Parts for KSV62HRA
W0014359 FILTER AIR
W0019566 FILTER AIR
.JPG)
W0019828 SENSOR INDOOR TEMP
W0019918 BOX CONTROL ASSY OUTDOOR
W0067849 MOTOR LOUVRE
W0069459 HOLDER BEARING
W0075340 SENSOR TEMP EVAPORATOR TEMP
W0094414 BOX CONTROL ASSY INDOOR
$260.95
W0094418 BOARD DISPLAY ASSY
W0094445 KELVINATOR AIRCON REMOTE CONTROL
W0103211 HOSE DRAIN
W0127090 SENSOR TEMP EVAPORATOR TEMP
W0014361 COVER TEMP SENSOR
$5.50
W0014365 BLADE FAN
W0014452 CAPAC 3UF 450V 2PIN SOLDER FAN
W0014478 FUSE
W0016778 VALVE 4-WAY
$120.00
W0016782 REAR NET ESD18HRB
$16.50
W0016794 SEPERATING BOARD ESD18HRB
$49.50
W0019563 BOX CONTROL INDOOR
$77.00
W0019564 COVER CONTROL BOX ASSY
$11.00
W0019565 LOURVE VERTICAL AIRFLOW DOWN
$54.90
W0019619 E-PARTS BOXS COVER KSV62HRA
$16.50
W0019650 MOTOR MOUNTING BRACKET ASSY
$66.00
W0019651 LEFT SUPPORTER KSV62HRA
$88.00
W0019652 SUPPORT BOARD. MOTOR HOLDER
$14.30
W0019656 TOP COVER ASSY KSV62HRA
$71.50
W0019704 COMPRESSOR ROTARY
$581.00
W0019820 TRANSFORMER
$80.35
W0019833 WIRE JOINT KSV62HRA
$14.30
W0068321 CLAMP CAPACITOR
W0068324 WASHER FOR WIRE JOINT ESD09HRA
W0068682 PLATE INSTALLATION
W0068690 FOAM OVEN HOLDER MOTOR ESE18C
W0068696 BIG HANDLE ESE18CRA
W0068703 PAN DRAIN
W0070406 HANDLE SMALL (ESG21HRIA)
W0070655 NUT FLARE TLM B02 3/8 9.52MM
$7.70
W0070731 PANEL FRONT RH (ESG21HRIA)
W0070736 PANEL REAR RH (ESG21HRIA)
W0071980 OUTDOOR TEMP SENSOR ESD09HRA
W0072244 COPPER NUT TLM-D04 5/8 15.88MM
W0072501 WIRE JOINT. 5P ESD09HRA
W0072508 COUPLING PIPE DRAINAGE INDOOR
W0072532 INSTALLATION BOX. E-PARTS
$27.50
W0072537 HOLDER. E-PARTS ESD18HRB
W0072538 SENSOR DISCHARGE TEMP 500MM
W0072541 REACTOR ESD18HRB
W0075156 CAPAC 50UF 450V 4 PIN COMPRESS
$55.00
W0075346 GRILL FRONT OUTDOOR
$40.00
W0075347 MOTOR FAN OUTDOOR
W0075350 BOARD. TERMINAL ESD18HRB
W0093668 CROSS FLOW FAN ASSY KSV62HRA
W0093674 WIRE CLAMP KSV62HRA
$4.50
W0093717 WIRE CLAMP. POWER CORD
$5.50
W0093774 PROTECTING PLATE KSV62HRA
$5.50
W0093780 BOX DISPLAY
$40.00
W0093784 DISPLAY BOARD ENCLOSURE
$14.30
W0093790 COVER. SMALL. MOTOR KSV62HRA
$8.80
W0093791 MOTOR COVER KSV62HRA
W0093792 SCREW CAP KSV62HRA
$5.50
W0093793 CHASSIS INDOOR
W0093794 LEFT HOLDER. EVAPORATOR
$14.30
W0093795 FRAME AIR OUT ASSY
W0093797 FRONT PANEL KSV62HRA
W0093799 FRONT FRAME ASSY KSV62HRA
$132.00
W0093800 LOURVE VERTICAL AIRFLOW UP
W0093801 PANEL ASSY KSV62HRA
$179.90
W0093802 SURROUND DISPLAY BOARD
$27.50
W0093807 COVER WINDOW
$60.00
W0093861 WIRE CLAMP KSV62HRA
$4.50
W0093889 CONNECTING PIPE CLAMP
$4.50
W0093890 PLATE INSTALLATION
$30.00
W0093891 RIGHT HOLDER. EVAPORATOR
$9.90
W0093915 COVER REACTANCE FILTER
$29.70
W0093916 BASE PLATE COMPRESSOR
$121.00
W0093954 COVER. INDUCTANCE KSV62HRA
W0093955 SUPPORT INDUCTOR
$14.30
W0093956 COVER INDUCTOR PROTECTOR
$13.20
W0094008 DISPLAY BOARD KSV62HRA
W0094024 MAIN CONTROL BOARD KSV62HRA
W0094075 EVAPORATOR ASSY
$383.50
W0094099 CONDENSOR COIL ASSY KSV62HRA
$396.00
W0094119 GAS PIPE VALVE KSV62HRA
$132.00
W0094121 LIQUID VALVE KSV62HRA
$51.70
W0094179 VALVE ASSY LOW PRESSURE
$308.00
W0094180 VALVE LIQUID ASSY
$103.40
W0094238 SOUND-PROOF MATERIAL
$11.00
W0094239 SOUND-PROOF MATERIAL
$22.00
W0094259 COIL REACTOR (R1815E)
$210.50
W0094260 COIL REACTOR (R1502)
$138.00
W0094295 RADIATOR KSV62HRA
$159.50
W0094308 MOTOR FAN INDOOR
$245.40
W0094368 RUBBER KSV53HRA
$5.50
W0094371 RUBBER UNDERLAY KSV62HRA
$14.30
W0094415 BOARD MAIN INDOOR
$190.90
W0094429 BLOCK TERMINAL CONNECTOR
$38.50
W0102580 SEAL CIRCUIT
$4.00
W0132295 FRONT CLAPBOARD ESD18HRB
