KSV62HRE — 950001221 00
KELVINATOR — Air-Conditioner
Parts for KSV62HRE
W0011173 COMPRESSOR KSV53HRE
$982.90
W0012109 EVAPORATOR ASSY
W0012197 CONDENSER ASSY
$391.95
W0012298 CLAPBOARD ASSY
$50.00
W0012332 FRAME, WALL MOUNTING
W0012347 TOP COVER KSV53HRC
$70.00
W0012378 PLATE ASSY, RIGHT SIDE
$44.95
W0012388 LEFT SIDE PLATE KSV53HRC
$27.50
W0012507 REAR GRILL KSV53HRC
$14.30
W0012599 SUPPORT, MOTOR SUB ASSY
$33.00
W0012609 VALVE SUPPORT SUB-ASSY
$12.10
W0012950 BOARD MAIN ASSY OUTDOOR ELECT
$516.50
W0013015 CHASSIS, SUB ASSY
W0013159 VALVE ASSY, 4-WAY
$259.95
W0013190 CAPILLARY, SUB ASSY
W0013517 HOSE DRAIN
W0013881 COUPLING CONNECTER DRAINAGE
W0013998 SEAL DRAINAGE
$6.00
W0014091 VALVE CUT-OFF SUCTION 5/8
$68.75
W0014092 VALVE, CUT OFF SUB-ASSY
W0014464 FAN AXIAL FLOW KSV53HRC
W0014489 BLADE FAN CROSS FLOW ASSY
W0014566 LOUVER, AIR
W0014631 BUSH AXILE
W0014667 CRANK
$5.50
W0015164 FILTER, SUB ASSY
$24.30
W0018910 MOTOR FAN OUTDOOR KSV62HRE
W0019455 FRONT PANEL ASSY
$57.35
W0019460 CASE ASSY, FRONT
$110.00
W0019461 CASE ASSY, REAR
W0019538 BOX. ELECTRIC ONLY
$40.00
W0019549 BOX ELECTRIC ONLY (FIRE PROOF)
$40.00
W0019604 COVER, BOX ELECTRIC 1
$10.00
W0019607 COVER, BOX ELECTRIC 2
$40.00
W0019938 BOARD MAIN ASSY INDOOR ELECT
$370.70
W0020514 COVER, VALVE
$10.00
W0020562 FRONT GRILL KSV53HRC
W0020661 SUPPORT, EVAPORATOR
W0020665 BAR, STAY SUB ASSY
$10.00
W0020777 TONGUE, HELICOID
W0020784 MOTOR PRESS PLATE KSV53HRC
$9.90
W0020858 RING OF BEARING KSV53HRC
$11.40
W0020885 HANDLE KSV53HRC
$29.55
W0020948 LOUVER, GUIDE
$15.40
W0021237 MAIN PCB INDOOR KSV62HRE
$218.05
W0021239 MAIN PCB OUTDOOR KSV62HRE
$599.20
W0021300 REMOTE CONTROL
W0021803 BOARD, DISPLAY
W0023282 SENSOR OUTDOOR KSV53HRE
$34.95
W0023290 SENSOR TEMPERATURE
W0023293 SENSOR INDOOR KSV53HRE
W0023350 CORD, POWER
$35.00
W0023356 CONNECTING CABLE(FOUR CORE)
$71.50
W0024729 TERMINAL BOARD 3-BIT ASSY
$20.00
W0024732 TERMINAL BOARD 4-BIT
$14.90
W0024862 COIL, MAGNETIC (4-WAY VALVE)
$50.00
W0024874 REACTOR KSV53HRC
$77.00
W0024938 SWITCH PRESSURE PROTECT
W0025271 RADIATOR
$40.00
W0026748 NUT, FLARE (ONE TIME) 16MM
$26.40
W0026749 NUT, FLARE (ONE TIME) 6.35MM
$11.00
W0026834 BEARING FAN BLADE
W0026850 PLUG WATER TRAY
W0047829 FRONT PANEL KSV53HRC
$116.10
W0089846 MOTOR FAN INDOOR WSV70HRB
W0090334 MOTOR LOURVE
$59.40
W0096142 SCREW COVER
$4.00
W0096482 PIPE CLAMP KSV53HRC
$4.00
W0096483 CLAMP WIRING
$4.50
W0096528 HANDLE
