KSV70HRA — 950001085 01
KELVINATOR — Air-Conditioner
Parts for KSV70HRA
W0014359 FILTER AIR
W0019566 FILTER AIR
.JPG)
W0019828 SENSOR INDOOR TEMP
W0019918 BOX CONTROL ASSY OUTDOOR
W0067849 MOTOR LOUVRE
W0069459 HOLDER BEARING
W0075340 SENSOR TEMP EVAPORATOR TEMP
W0094418 BOARD DISPLAY ASSY
W0094445 KELVINATOR AIRCON REMOTE CONTROL
W0103211 HOSE DRAIN
W0014361 COVER TEMP SENSOR
$5.50
W0014452 CAPAC 3UF 450V 2PIN SOLDER FAN
W0014475 PAN DRAIN
$24.90
W0014478 FUSE
W0019563 BOX CONTROL INDOOR
$77.00
W0019564 COVER CONTROL BOX ASSY
$11.00
W0019565 LOURVE VERTICAL AIRFLOW DOWN
$54.90
W0019619 E-PARTS BOXS COVER KSV62HRA
$16.50
W0019637 PLATE PARTITION RH OUTDOOR
$88.00
W0019638 BRACKET MOTOR
$99.00
W0019643 SUPPORTER. BACK KSV70HRA
$14.30
W0019644 COVER REACTANCE FILTER
$29.70
W0019704 COMPRESSOR ROTARY
$581.00
W0019729 CONDENSOR ASSY
$381.70
W0019820 TRANSFORMER
$80.35
W0019833 WIRE JOINT KSV62HRA
$14.30
W0019854 MOTOR FAN
$325.00
W0068321 CLAMP CAPACITOR
W0068324 WASHER FOR WIRE JOINT ESD09HRA
W0069292 COVER TOP OUTDOOR
W0069295 HANDLE LARGE OUTDOOR
W0069296 HANDLE SMALL
$10.00
W0069300 CLAMP CONTAINER REFRIGERANT
W0069683 BLADE FAN
W0069695 VALVE HIGH PRESSURE
$22.00
W0070655 NUT FLARE TLM B02 3/8 9.52MM
$7.70
W0071980 OUTDOOR TEMP SENSOR ESD09HRA
W0072244 COPPER NUT TLM-D04 5/8 15.88MM
W0072315 REAR RIGHT CLAPBOARD MSE30CR
W0072316 INSTALLATION PLATE VALVES MSE
W0072321 SENSOR TEMP (CONDENSOR)
W0072501 WIRE JOINT. 5P ESD09HRA
W0072508 COUPLING PIPE DRAINAGE INDOOR
W0072532 INSTALLATION BOX. E-PARTS
$27.50
W0072537 HOLDER. E-PARTS ESD18HRB
W0072538 SENSOR DISCHARGE TEMP 500MM
W0072541 REACTOR ESD18HRB
W0075140 4-WAY VALVE ESD18HRB
W0075156 CAPAC 50UF 450V 4 PIN COMPRESS
$55.00
W0075346 GRILL FRONT OUTDOOR
$40.00
W0093668 CROSS FLOW FAN ASSY KSV62HRA
W0093674 WIRE CLAMP KSV62HRA
$4.50
W0093718 WIRE CLAMP. POWER CORD
$5.50
W0093774 PROTECTING PLATE KSV62HRA
$5.50
W0093780 BOX DISPLAY
$40.00
W0093784 DISPLAY BOARD ENCLOSURE
$14.30
W0093790 COVER. SMALL. MOTOR KSV62HRA
$8.80
W0093791 MOTOR COVER KSV62HRA
W0093792 SCREW CAP KSV62HRA
$5.50
W0093793 CHASSIS INDOOR
W0093794 LEFT HOLDER. EVAPORATOR
$14.30
W0093795 FRAME AIR OUT ASSY
W0093797 FRONT PANEL KSV62HRA
W0093799 FRONT FRAME ASSY KSV62HRA
$132.00
W0093800 LOURVE VERTICAL AIRFLOW UP
W0093801 PANEL ASSY KSV62HRA
$179.90
W0093802 SURROUND DISPLAY BOARD
$27.50
W0093807 COVER WINDOW
$60.00
W0093842 WATERPROOF BOARD KSV70HRA
$8.80
W0093845 REAR NET KSV70HRA
$29.70
W0093861 WIRE CLAMP KSV62HRA
$4.50
W0093889 CONNECTING PIPE CLAMP
$4.50
W0093890 PLATE INSTALLATION
$30.00
W0093891 RIGHT HOLDER. EVAPORATOR
$9.90
W0093918 BASE PLATE COMPRESSOR
$165.00
W0093919 BOARD. TERMINAL KSV70HRA
W0093926 LEFT SUPPORTER KSV70HRA
$14.30
W0093928 FRONT RIGHT CLAPBOARD KSV70HRA
W0093929 FRONT PANEL KSV70HRA
W0093954 COVER. INDUCTANCE KSV62HRA
W0093955 SUPPORT INDUCTOR
$14.30
W0093956 COVER INDUCTOR PROTECTOR
$13.20
W0094008 DISPLAY BOARD KSV62HRA
W0094024 MAIN CONTROL BOARD KSV62HRA
W0094077 EVAPORATOR ASSY
W0094183 SUCTION PIPE ASSY KSV70HRA
$132.00
W0094184 ACCUMULATOR
W0094185 VALVE LIQUID ASSY
$160.00
W0094186 VALVE ASSY LOW PRESSURE
$200.20
W0094238 SOUND-PROOF MATERIAL
$11.00
W0094239 SOUND-PROOF MATERIAL
$22.00
W0094259 COIL REACTOR (R1815E)
$210.50
W0094260 COIL REACTOR (R1502)
$138.00
W0094295 RADIATOR KSV62HRA
$159.50
W0094308 MOTOR FAN INDOOR
$245.40
W0094367 RUBBER KSV70HRA
$4.50
W0094369 RUBBER ADJUSTING MASS
$11.00
W0094419 BOARD MAIN INDOOR
W0094431 BLOCK TERMINAL ASSY
$33.00
W0102580 SEAL CIRCUIT
$4.00
W0132300 VALVE ASSY LOW PRESSURE
