KTM3900PC — 925042791
KELVINATOR — Fridge
Parts for KTM3900PC
W0018417 HEATER DEF & DTT R600A 690W
W0019131 SCREW COUNTER SUNK THIMBLE
$4.50
.JPG)
W0083263 STOP DOOR
W0085498 SHELF GLASS 599.92 X X344.79MM
.JPG)
W0085600 CAP LEG
$12.90
W0085609 LEG STABILISING
W0086637 HOSE DRAIN (SLIT 130MM)
$11.90
.JPG)
W0086638 BLADE FAN
.JPG)
W0086775 SWITCH LAMP
W0086833 WESTINGHOUSE FRIDGE DOOR BOTTOM HINGE PLATE R/H
W0087127 BIN CRISPER
.JPG)
W0087130 DOOR DAIRY
W0087136 BIN CAN
$56.40
W0087145 BIN DOOR FZR
W0087213 HINGE TOP RH
W0087464 ROLLER REAR GREY
W0087646 GASKET DOOR FC
$90.90
.JPG)
W0088096 MOTOR FAN EVAP
W0159670 DRIER 12GM(XH9)DBLE/SGLE TAIL
W0018042 BRACKET FAN MOTOR
$7.00
W0018049 CLIP SELF ADHESIVE
$9.00
W0018081 SHROUD FAN MOULDED RJ393V
W0018166 GROMMET FAN MOTOR
$16.45
W0018170 GROMMET COMPRESSOR
W0018232 COVER HINGE RH ETE3900SA
$4.00
W0018254 CAP CORNER GREY SYD1212A
$23.80
W0018383 GASKET LAMP SEALING
$7.70
W0018624 PAN DRAIN WANBAO ETZ110
$21.10
W0081199 TIE CABLE 140MM LONG
W0081263 PIN COMPRESSOR MTG RS652M*6
W0082722 FOAM TAPE RJ393V
W0083869 PLUG DRAIN WHT
W0084491 SEAL BYPASS PLASTIC N410F
W0084558 DAMPER NOISE
W0084749 CLAMP-CORD BJ385T
W0085278 INSULATION EVAP COVER RJ393V
W0085488 SHELF FREEZER RJ393V
W0085599 SPACER ROLLER STRIKESIDE RJ393
W0085622 TROUGH DRAIN SR300B
W0085638 COVER LAMP
$14.90
W0085702 ROLLER ADJUSTABLE RJ393V
W0085947 PLUG SCREW
$3.90
W0086053 THIMBLE FILLER ASSY CLOSED
W0086056 THIMBLE CAM ASSY CLOSED RJ393V
W0086131 COVER TOGGLE LOCK SR300B
W0086323 TRIM SHELF FREEZER 556MM
W0086339 SCREW M4 X 8 MUSH RJ393V
W0086441 GASKET DEL TOP N280J
W0086447 CAP
$12.90
W0086579 TAPE FOAM SEALING SBM3800MA
W0086829 EPS UPPER KTM3900M
W0086844 KNOB CONTROL KTM4200WA
W0087125 BIN BOTTLE ASSY STM3000WA
W0087143 BIN HALF WIDTH
W0087334 PAD STOP SKID ROLLER
W0087402 SCREW 8/32 X 3/8 ETM3600WB
W0087403 CLIP MOUNTING COMPRESSOR
W0087405 SCREW 12/14 16MM ETM3600WB
W0087406 SCREW-HINGE/CAM-BTM ETM3600WB
$4.50
W0087407 SCREW 8/32 X 1/2THREAD FORMING
W0087409 SCREW EVAP COVER 8 X 1/2
$4.00
W0087411 SCREW HINGE CENTRE
$4.50
W0087412 SCREW ETM3600WB
W0087416 SCREW 8 X 1/2 T/F ETM3600WB
W0087417 NUT ETM3600WB
W0087418 SCREW 8 X 19 T/CT TBT
$5.50
W0087422 LOCK WASHER ESE6108WA
W0087496 HINGE DOOR CENTRE GREY
W0087497 CAP SCREW GREY
W0087593 BASE PLATE COMP ASSY STM4200W
W0087642 GASKET DOOR FZR
W0087671 SHIELD LIGHT KTM3900MB
W0087721 COVER EVAP WTM4200PA
W0087731 HEAT SHIELD EVAP COVER
W0087735 TROUGH DRAIN WTM4200PA
W0087742 LAMP 40W SES 240V T25
W0087822 SHAFT ROLLER
$7.00
W0088005 EVAP ASSY R600A ETM4200SC
W0088119 HOUSING CTRL TOP ASSY KELV
W0088159 COM R600A EMB66CLC EMBRACO
W0088182 CORD SERVICE INSULATED R600A
W0088186 CAPAC 4UF 400V 2 WIRE CLIP IN
W0088213 HUMIDITY CONTROL KBM3800MB
W0088224 LID CRISPER ASSY (WATER CLEAR)
W0088226 EPS UPPER KTM3900M
W0088230 CTRL BRD ERF450 & KIT ASSY
W0088232 COVER EVAP ASSY EBM4307SC
W0088702 BADGE NAMEPLATE
$8.70
W0088772 DOOR ASS KTM RH F/C PACIF
W0088773 DOOR ASS KTM RH FZR PACIF
W0088782 COVER COMPRESSOR
$14.90
W0134824 TAPE TESSA MOL 4761
