SWF12843 — 914900515 01
SIMPSON — Washing Machine
Parts for SWF12843
W0016638 GASKET DRUM SHAFT
$21.41
W0016981 VALVE SOLENOID 2-WAY
W0017020 SHAFT, DOOR HINGE, 112MM
$7.50
W0017025 RING LOCKING
W0017029 SPRING, BELLOW, TUB, G33
$11.25
W0017076 ELEMENT HEATING
W0017087 DISPENSER DETERGENT ASSY
W0017089 DRAWER DETERGENT
W0017199 BOLT SHOCK ABSORBER
W0017224 LOW FREQENCY ANALOG PRESSUR
W0018790 HOSE PRESSURE SENSOR L620
$4.99
W0026627 BEARING DRUM (6206Z)
W0026925 SIMPSON FRONT LOADER WASHING MACHINE MAIN PC BOARD EWX11 SWF12843
W0026973 GASKET, BELLOW
W0027172 MOTOR CIM AL STK50 P69
$201.86
W0027221 HOSE DRAIN ASSY
W0027242 LOCK DOOR
W0027278 PCB ASSEMBLY, MOTOR CONTROL LP
W0029486 SIMPSON WESTINGHOUSE WASHING MACHINE PCB INTERFACE
W0029594 CONTROL PANEL+HANDLE PRINTED
W0048965 HOOK OUTLET HOSE
W0060454 WASHING MACHINE HOSE ASSY INLET COLD BLUE
W0075951 BELT DRIVE
W0075967 PULLEY PLASTIC
$20.63
W0147298 BUSHING HINGE
$3.38
W0015051 NUT, PLASTIC EWN14991W
$3.38
W0016559 SCREW PULLEY
$3.38
W0016881 SCREW SHELL TUB 6 5X50
$3.38
W0016906 SHOCK ABSORBER ASSY
W0016944 CAP REAR PANEL
$12.00
W0016969 TRANSIT BOLT KIT HEC54
$51.00
W0017083 SCREW COUNTERWEIGHT TOP
$3.00
W0017088 CONVEYOR ASSY
$11.78
W0017090 PARTITION DRAWER RIB
$4.28
W0017097 PUMP DRAIN LEILI
W0017098 CLAMP DET DISPENSER GASKET
W0017104 SUPPORT,HOSE DRAIN,HIGH
W0017108 SUPPORT,HOSE DRAIN,LOW
$6.56
W0017176 SPRING, TUB SUSPENSION
$9.49
W0018719 SEAL DRUM OUTER REAR
$20.48
W0018732 CORD POWER SUPPLY AUSTRALIA
$13.69
W0018746 HOSE VALVE CONNECTION+CLAMP
$8.29
W0018748 HOSE VALVE CONNECTION+CLAMP
$8.29
W0026168 SCREW, HINGE
W0026228 BEARING BALL 25X52X15
W0026970 SCREW MOTOR (8X30 TE)
$3.00
W0027062 HINGE, PORTHOLE
W0027076 FRAME, FRONT, PORTHOLE WHITE
W0027078 FRAME, BACK, PORTHOLE, GREY
W0027079 LATCH, DOOR
W0027080 VALVE FLOATING
$30.98
W0027083 DIAPHRAGM
W0027088 DRAIN BODY INTEGRATED
$3.49
W0027094 PANEL, FRONT
$74.06
W0027095 FILTER DIAPHRAGM
$17.10
W0027098 GLASS, PORTHOLE
$101.25
W0027099 PROTECTION DOOR LOCK
$3.38
W0027108 LIFTER DRUM
$14.03
W0027122 SYPHON ADDITIVE
$3.30
W0027125 BRACKET, CONTROL PANEL
$10.73
W0027142 SPRING ON/OFF BUTTON
$6.11
W0027143 BUTTON ON/OFF
$6.98
W0027148 WORK TOP ASSEMBLY
W0027183 GASKET CONTROL PANEL
$6.60
W0027217 WIRING HARNESS ASSY COMPLETE
$62.25
W0027230 SUPPORT SHOCK ABSORBER
$24.00
W0027249 TUB SHELL FRONT P69
$38.21
W0027252 TUB SHELL REAR
$128.25
W0029236 AIR CHAMBER ASSY
$9.45
W0029298 COUNTER WEIGHT TOP
$33.00
W0029301 COUNTER WEIGHT FRONT
$39.79
W0029344 CROSS SPIDER ASSEMBLY
W0029348 DRUM ASSY P69/1200
$222.41
W0074340 SCREW BEARING SPIDER
W0075275 CLAMP CABLE
W0075997 FOOT ADJUSTABLE ASSY
W0076105 BRACKET SUSPENSION
W0076221 PANEL, BACK, HIGH
W0076228 HINGE REINFORCEMENT
