SWF12843 — 914900515 03
SIMPSON — Washing Machine
Parts for SWF12843
W0016638 GASKET DRUM SHAFT
$28.55
W0016981 VALVE SOLENOID 2-WAY
W0017020 PIN DOOR HINGE
$10.00
W0017025 RING LOCKING
W0017029 SPRING, BELLOW, TUB, G33
$15.00
W0017076 ELEMENT HEATING
W0017087 DISPENSER DETERGENT ASSY
W0017089 DRAWER DETERGENT
W0017199 BOLT SHOCK ABSORBER
W0017224 LOW FREQENCY ANALOG PRESSUR
W0018790 HOSE PRESSURE SENSOR L620
$6.65
W0026627 BEARING DRUM (6206Z)
W0026973 GASKET, BELLOW
W0027172 MOTOR CIM AL STK50 P69
$269.15
W0027221 HOSE DRAIN ASSY
W0027242 LOCK DOOR
W0029486 SIMPSON WESTINGHOUSE WASHING MACHINE PCB INTERFACE
W0029594 CONTROL PANEL+HANDLE PRINTED
W0048965 HOOK OUTLET HOSE
W0060454 WASHING MACHINE HOSE ASSY INLET COLD BLUE
W0075951 BELT DRIVE
W0075967 PULLEY PLASTIC
$27.50
W0147298 BUSHING HINGE
$4.50
W0015051 NUT, PLASTIC EWN14991W
$4.50
W0016559 SCREW PULLEY
$4.50
W0016881 SCREW SHELL TUB 6 5X50
$4.50
W0016906 SHOCK ABSORBER ASSY
W0016944 CAP REAR PANEL
$16.00
W0016969 TRANSIT BOLT KIT HEC54
$68.00
W0017083 SCREW COUNTERWEIGHT TOP
$4.00
W0017088 CONVEYOR ASSY
$15.70
W0017090 PARTITION DRAWER RIB
$5.70
W0017097 PUMP DRAIN LEILI
W0017098 CLAMP DET DISPENSER GASKET
W0017104 SUPPORT,HOSE DRAIN,HIGH
W0017108 SUPPORT,HOSE DRAIN,LOW
$8.75
W0017176 SPRING, TUB SUSPENSION
$12.65
W0018719 SEAL DRUM OUTER REAR
$27.30
W0018732 CORD POWER SUPPLY AUSTRALIA
$18.25
W0018746 HOSE VALVE CONNECTION+CLAMP
$11.05
W0018748 HOSE VALVE CONNECTION+CLAMP
$11.05
W0026168 SCREW, HINGE
W0026228 BEARING BALL 25X52X15
W0026970 SCREW MOTOR (8X30 TE)
$4.00
W0027062 HINGE, PORTHOLE
W0027076 FRAME, FRONT, PORTHOLE WHITE
W0027078 FRAME, BACK, PORTHOLE, GREY
W0027079 LATCH, DOOR
$8.80
W0027080 VALVE FLOATING
$41.30
W0027083 DIAPHRAGM
W0027088 DRAIN BODY INTEGRATED
$4.65
W0027094 PANEL, FRONT
$98.75
W0027095 FILTER DIAPHRAGM
$22.80
W0027098 GLASS, PORTHOLE
$135.00
W0027099 PROTECTION DOOR LOCK
$4.50
W0027108 LIFTER DRUM
$18.70
W0027122 SYPHON ADDITIVE
$4.40
W0027125 BRACKET, CONTROL PANEL
$14.30
W0027142 SPRING ON/OFF BUTTON
$8.15
W0027143 BUTTON ON/OFF
$9.30
W0027148 WORK TOP ASSEMBLY
W0027183 GASKET CONTROL PANEL
$8.80
W0027230 SUPPORT SHOCK ABSORBER
$32.00
W0027249 TUB SHELL FRONT P69
$50.95
W0027252 TUB SHELL REAR
$171.00
W0029236 AIR CHAMBER ASSY
$12.60
W0029298 COUNTER WEIGHT TOP
$44.00
W0029301 COUNTER WEIGHT FRONT
$53.05
W0029344 CROSS SPIDER ASSEMBLY
W0029348 DRUM ASSY P69/1200
$296.55
W0029602 BRACKET SPRING SUPPORT
$19.75
W0030098 PCBA MOTOR CONTROL EMC14 CIM
$205.00
W0074340 SCREW BEARING SPIDER
W0075275 CLAMP CABLE
W0075997 FOOT ADJUSTABLE ASSY
W0076221 PANEL REAR
W0076228 HINGE REINFORCEMENT
W0274078 PCBA MB EWX14 POTTED SWF12843
W0275611 WIRING HARNESS ASSY COMPLETE
$85.00
