WFE517SA — 940001824 23
WESTINGHOUSE — Cooker Dual Fuel

W0011319 COVER GRILL DISH

W0011404 TRAY SCONE

$15.92

W0011922 HANDLE DOOR

$25.68

W0012254 ELEMENT C/HEAT 1800W SS321

W0012262 ELEMENT FAN RING 2200W

W0012326 CLIP MOUNTING ELEMENT

W0012570 END CAP HANDLE BLK WEST NGD

$11.24

W0012724 SEAL VALVE SOURDILLON

W0012861 DOOR OVEN INNER GLASS

W0012990 SPACER HANDLE BLK FRESCO

$8.20

W0013596 SWITCH THERMAL CUT OUT 190 DEG

W0013627 TRIM DOOR UPPER VENTED

W0013702 TIMER 120 MINUTE WESTLAKE

W0013858 KIT INDICATOR LIGHT FRESCO

W0013996 BOX IGNITION 4P 240V HMJD

W0014040 SCREW 3/16X28 PAN PH TRILOB ZY

W0022619 BURNER SEMI-RAPID CYLIND

$32.00

W0022624 BURNER CROWN AUX CYLINDER

W0022734 THERMOCOUPLE 500MM WOK

$25.32

W0022742 SPARK PLUG IGNITOR 600 MM

W0022807 HINGE DOOR OVEN

W0027342 GRILL DISH GIO ENAMEL

$84.36

W0029488 GRILL GRABBER FORTE

$3.60

W0032275 LAMP 25W 240V G9 PYRO HALOPIN

W0050403 MOTOR FAN OVEN

W0053487 SHELF OVEN 473 X 378MM

W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101

W0057210 SWITCH AUXILIARY T/STAT

W0057771 THERMOSTAT OVEN

W0147339 SEAL OVEN MODULAR PROFILE

W0271174 IMPELLER OVEN FAN 160 MM

W0275063 LAMP OVEN ROUND PYRO BIOS

W0365427 SWITCH AUXILIARY T/STAT

$19.68

W0011114 TERMINAL BLOCK W/EARTH BIOS

W0011126 BASE BURNER AUX IGN NG

$23.24

W0011366 BRACKET HOB SUPPORT FRESCO

$7.92

W0011385 BRACKET GAS RAIL F/F DUAL FRES

$7.92

W0011388 SYNC GRILL SLIDE HANDLE FRESCO

$39.72

W0011461 PNL OUT OV DR ASS 540 WEST S/S

$140.40

W0011465 PNL OUT GR ASSY 540 WEST SS SM

$120.24

W0011514 PANEL SIDE SS VINYL FRESCO

$100.24

W0011631 PANEL CONTROL SCREEN WFE517SA

$61.60

W0011666 COVER FAN & ELEMENT

$76.60

W0011701 SPALSHBACK 540S/S FRESCO

$22.40

W0011845 HINGE GR DOOR 540 FRESCO PH2

$6.16

W0011846 HINGE GR DOOR 540 FREE FRESCO

$43.08

W0011972 TUBE BURNER 540 L/F FRESCO FF

W0011973 TUBE BURNER 540 L/R FRESCO FF

$19.36

W0011974 TUBE BURNER 540 R/F FRESCO FF

$19.36

W0011975 TUBE BURNER 540 R/R FRESCO FF

$19.36

W0012315 CLIP THERMOSTAT BIOS

$7.20

W0012417 SUPPORT COUNTER FRESCO

$5.64

W0012576 ENDCAP C/PANEL FRESCO S/S PAIR

W0012911 CANOPY GRILL ELEC FRESCO

$22.00

W0012989 SPACER HANDLE SS FRESCO

W0013239 PIPE MANIFOLD F/FAIL DUAL FUEL

W0013260 SHIELD WIRING

$9.56

W0013336 INSULATION GRILL BACK ELEVATED

$11.44

W0013342 INSUL GRILL CANOPY TOP FRESCO

$11.44

W0013460 BRACE OVEN REAR 540 BIOS

$22.00

W0013561 SWITCH HARNESS 4P SOURD 600SI

$61.52

W0013731 BUMPER STOP GREY

$4.04

W0013777 HOB 540F S/S GAS WOK FF NOPLAS

$205.56

W0014019 SCREW #6X3.5X28 HILO PAN PH

$3.60

W0014026 SCREW #8 X 5/16 CSK #2PH AB BK

$3.60

W0014029 SCREW #8 X 1/2 MUSH PH#2 AB BK

W0014030 SCREW #8 X 8MM HEX/MULTI

$3.60

W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK

$3.60

W0021318 SCREW M4X5 PHIL HZ

W0021330 NUT METRIC M10 X 0.75MM

W0021433 FOOT TRIVET

$5.64

W0021570 VALVE BSI FSG AUX

W0021571 VALVE BSI FSG SEMI RAPID

W0021573 VALVE BSI FSG T/C

W0021781 PLATE MTG SWITCH S/G GAS WEST

$11.44

W0022171 FOOT LEVELING

$13.08

W0022627 BURNER CAP MATTE SEMI-R CYLIND

$17.88

W0022628 BURNER CAP MATTE AUX CYLINDER

$17.88

W0022744 SPARK PLUG IGNITOR 900 MM

W0029306 PLATE CVR TERM GAS 540 BIOS

$10.44

W0029350 540 LOWER REAR BRACE

$10.08

W0029662 ANTI TILT PLATE

$12.52

W0029771 BRKT HOB MOUNT REAR 540FC ASSY

$12.08

W0035788 DEFLECTOR HEAT GRILL UC20

W0039904 PANEL CABINET REAR (WITH HOLE)

$22.00

W0041126 PANEL SEALING GAS 540 BIOS

W0043118 PANEL REFLECTOR GRILL TOP

W0044064 NUT M6 LH FAN MOTOR ECM

W0044830 FLUE DUCT OVEN ELEC 540 BIOS

W0046413 CLIP SPARK PLUG E/LUX

W0046662 TRIVETT CAST WEST 540 FRESCO

W0046665 TRIVETT CAST WEST 540 WOK FRES

W0047180 SUPPORT GRILL ELEMENT

W0048105 ENDCAP C/PANEL FRESCO S/S LHS

W0052926 SPACER FOOT UC20

W0054645 INSULATION OVEN CABINET

W0054646 INSULATION OVEN BACK BIOS

W0064527 SCREW NO 8 X 12 MM PD

$3.60

W0064592 SCREW TORQ #4 X 12 # PAN HEAD

W0064625 SCREW #8X20 TYP 17 PT TORX BLK

W0065401 SCREW VALVE CLAMP 25MM

$3.60

W0102393 SPARK PLUG WOK 900MM

W0109968 T'COUPLE TT ELUX BURNER 275

W0109970 THERMOCOUPLE 500MM

W0110088 BURNER ASSY TRIPLE CROWN WOK

W0110096 BURNER BODY ASSY S/RAP IGN NG

W0110103 BURNER ASSY WOK NG

$32.00

W0110205 CAP BURNER KIT

$29.60

W0154046 SLIDER GRILL DOUBLE ACTION LH

$35.20

W0154047 SLIDER GRILL DOUBLE ACTION RH

$35.20

W0154099 KNOB ASSY SILVE WEST GAS FRSCO

W0275742 PANEL KICK 540 SML WHT PREPAIN

$20.04

W0275749 F/FRONT 540FC SEP GRILL

$36.84
