WDE135WA-L — 940001836 02
WESTINGHOUSE — Cooker Electric
Parts for WDE135WA-L
.JPG)
W0011297 BLADE FAN
.JPG)
W0011400 DISH GRILL ENAM SEP GRILL
$68.20
W0011404 TRAY SCONE
$19.90
.JPG)
W0011909 HANDLE GRILL DISH
$9.90
W0011995 NUT M6 LH FAN MOTOR
W0012254 ELEMENT C/HEAT 1800W SS321
.JPG)
W0012259 ELEMENT EGO 2000W 180DIA (HI)
.JPG)
W0012260 ELEMENT EGO 1000W 145DIA (HI)
$96.00
W0012262 ELEMENT FAN RING 2200W
.JPG)
W0012326 CLIP MOUNTING ELEMENT
W0012570 END CAP HANDLE BLK WEST NGD
$14.05
.jpg)
W0012990 SPACER HANDLE BLK FRESCO
$10.25
.JPG)
W0013596 SWITCH THERMAL CUT OUT 190 DEG
W0013627 TRIM DOOR UPPER VENTED
W0013750 LENS INDICATOR LIGHT
$11.20
W0013858 KIT INDICATOR LIGHT FRESCO
W0014040 SCREW 3/16X28 PAN PH TRILOB ZY
W0022807 HINGE DOOR OVEN
W0023241 HOLDER LAMP ASSY BIOS
W0046262 ELEMENT EGO 1500W 145DIA (HI)
_1.JPG)
W0050403 MOTOR FAN OVEN
W0053461 RACK GRILL INSERT
.JPG)
W0053487 SHELF OVEN 473 X 378MM
.JPG)
W0057166 CHEF SIMPSON WESTINGHOUSE COOKTOP CONTROL SWITCH MP101
.JPG)
W0057210 SWITCH AUXILIARY T/STAT
.JPG)
W0057771 THERMOSTAT OVEN
.JPG)
W0060755 TIMER 60 MINUTE WESTLAKE
W0147339 SEAL OVEN MODULAR PROFILE
W0011114 TERMINAL BLOCK W/EARTH BIOS
W0011233 KNOB WEST 540 WHT FC GAS FRESC
W0011334 BRACKET ASSY ELEMENT 145MM
$12.60
W0011335 BRACKET ASSY ELEMENT 180MM
$18.00
W0011362 BRACKET SUPPORT TERMINAL BLOCK
W0011366 BRACKET HOB SUPPORT FRESCO
$9.90
W0011387 BRACKET ANTIROTATE SOLID FRSCO
W0011607 PNL CNT S/B SCR 510/511 BIOS
W0011660 PANEL CONTROL SCREEN WDE135WA
$121.85
W0011666 COVER FAN & ELEMENT
$95.75
W0011845 HINGE GR DOOR 540 FRESCO PH2
$7.70
W0011846 HINGE GR DOOR 540 FREE FRESCO
$53.85
W0011873 CHANNEL SPILL VENT 540 GIO
$22.00
W0011929 HNDL DOOR WEST 7820 WHITE
$60.95
W0011993 NUT METRIC M10 X 0.75MM
$4.50
W0012315 CLIP THERMOSTAT BIOS
$9.00
W0012853 GLASS OV DR IN REFL FRESCO
W0012911 CANOPY GRILL ELEC FRESCO
$27.50
W0013260 SHIELD WIRING
$11.95
W0013267 SHIELD WIRING HOB RC GAS FRES
$30.00
W0013328 INSULATION OVEN BACK - KNAUF
$20.30
W0013336 INSULATION GRILL BACK ELEVATED
$14.30
W0013342 INSUL GRILL CANOPY TOP FRESCO
$14.30
W0013460 BRACE OVEN REAR 540 BIOS
$27.50
W0013731 BUMPER STOP GREY
$5.05
W0014019 SCREW #6X3.5X28 HILO PAN PH
$4.50
W0014026 SCREW #8 X 5/16 CSK #2PH AB BK
$4.50
W0014030 SCREW #8 X 8MM HEX/MULTI
$4.50
W0014033 SCREW #8 X 12 UNDERCUT PAN BLK
$4.50
W0014034 SCREW #8 X 1/2 MUSH #2PH AB BK
$4.50
W0014060 WASHER SPRING ZP 6X2.5X1.6MM
W0021773 PLT MTG SWTCH MULTI 7 SGO FRES
$14.30
W0029931 PANEL CROWN ELEV ENAM FRESCO
$155.95
W0029932 F/FRONT PAINT ELEV GRILL FRESC
$70.00
W0029933 F/FRONT PAINT ELEV OVEN FRESCO
W0029940 PNL SIDE GRILL OUT R/H ELV FRE
$52.80
W0029941 PNL SIDE GRILL IN L/H ELEV FRE
W0029943 PNL SIDE OVEN OUT L/H ELEV FRE
$155.95
W0029946 PNL SIDE OVEN INN R/H ELEV FRE
W0029949 SUPPORT HINGE LH OVEN ELEV FRS
W0029950 SUPPORT HINGE RH OVEN ELEV FRS
W0030010 PNL SHIELD OVEN ENAM ELEV FRES
W0030023 DUCT OVEN ASSY ELEV ELEC FRESC
$10.00
W0030025 PANEL BACK WIRING GRILL ELEV F
$22.00
W0030026 PANEL BACK WIRING OVEN ELEV
W0030027 ANGLE STIFFENER OUTER BACK ELE
W0030093 PNL OUT OV DR ASS 540 WEST PRE
W0030106 PNL OUT GR DR ASSY 540 SMALL P
W0030114 PANEL HEAT SHIELD END CAP RH
W0030115 PANEL HEAT SHIELD END CAP LH
W0030188 BRACKET ANTI TILT ELEVATED
$12.60
W0035788 DEFLECTOR HEAT GRILL UC20
W0036207 RACK SIDE GRILL
W0038839 BRACKET SUPPORT HOB 600RC LHS
W0038840 BRACKET SUPPORT HOB 600RC RHS
W0039885 PANEL TOP REAR
W0043118 PANEL REFLECTOR GRILL TOP
W0047180 SUPPORT GRILL ELEMENT
W0047469 SCREW M4 X 5 PAN #2 PH SML HD
$4.50
W0048099 END CAP CONTROL PANEL FRESCO L
W0048100 END CAP CONTROL PANEL FRESCO R
W0048101 ENDCAP REAR CONTROL PANEL RHS
W0048102 ENDCAP REAR CONTROL PANEL LHS
W0049998 SEAL HOB SIDE 855MM ELEV
$43.40
W0052926 SPACER FOOT UC20
W0054672 INSULATION OVEN WRAP - KNAUF
$63.85
W0056177 GRILL BOX ENAM 540 BIOS
W0056765 FOOT BASE ELEVATED
W0064486 SCREW 3/16X28 PAN PH TRILOB BK
W0064532 SCREW #8 X 9/16 B/HD S/PT BKOX
$4.00
W0064747 NUT HEX 3/16 BSW
$4.50
W0065458 NUT HEX M6
$4.50
W0274247 HOB ASS SOL SG ELEV FRESCO
$275.00
