ALL ELECTRICAL WORK MUST BE PERFORMED BY A LICENSED ELECTRICIAN

WTB4604SA — 925060008 00
WESTINGHOUSE — Fridge

Parts for WTB4604SA

W0018582 BADGE NAMEPLATE
W0020667 PCBA 3 LEDS CLUSTER GALAGA
W0020674 TERMINAL BLOCK TH1116Y
W0027096 BOARD G SSLB WBE4500SA
$134.89
W0027433 CAPACITOR 4UF
$11.18
W0027439 SCREW TRILOB M5X16
$3.38
W0027522 COVER SCREW
$3.38
W0027529 GROMMET FAN SIDE
$6.56
W0027532 MOTOR FAN L 240V/50HZ 350MM TY
W0027540 SHROUD FAN
$41.25
W0027560 GROMMET COMPRESSOR
$8.63
W0027562 CLAMP NTC EVAPORATOR
W0027610 CLAMP COMPRESSOR
$3.38
W0029453 DRAWER CRISPER BODY TF70
W0029587 HARNESS-ASSY SENSOR DEFROST
W0029699 FOOT BASE THREAD
$6.56
W0029701 FOOT LEVER
W0029735 HANDLE RH ASSY
W0087752 BLADE FAN
W0154018 PCB ERF1600 PROGRAMED WTB4604
No image available
W0018166 GROMMET FAN MOTOR
$12.34
No image available
W0020669 LENS 3 LEDS CLUSTER GALAGA
$20.10
No image available
W0020681 CLAMP CABLE JIAX-C
$3.38
No image available
W0020682 TERMINAL COVER JIAX-C
$6.75
No image available
W0027461 BIN ICE COOL MINT
No image available
W0027539 BRACKET MOUNT FAN SURROUND
$10.88
No image available
W0027597 GASKET FZR TF70
$78.75
No image available
W0027599 GASKET FC TF70
No image available
W0029309 HINGE TOP RIGHT
$6.49
No image available
W0029332 DUCT EVAPORATOR
No image available
W0029334 COVER EVAP ASSY TF70 WH/KL
$34.39
No image available
W0029373 SUPPORT EVAPORATOR LEFT TF
$4.65
No image available
W0029374 TRAY EVAP DRAIN TF70W
$12.38
No image available
W0029396 DOOR BIN LOCKABLE TF70 WH ASY
No image available
W0029410 DOOR BIN FC SHALL 70 WH-HOTFOI
No image available
W0029421 DOOR BIN FC BOTTLE TF70W
No image available
W0029438 SHELF FZR TF70 ASSY
$56.85
No image available
W0029444 MULTIFLOW ASSY LED TF
$78.94
No image available
W0029445 SHELF FC TF70W
No image available
W0029449 SHELF FC TF70W WH ASSY
$63.45
No image available
W0029464 DIVIDER DRAWER TF WH ART
No image available
W0029465 COVER TOP HINGE RIGHT GR
$3.38
No image available
W0029536 BEARING AUTO CLOSER R TF SL
No image available
W0029561 HEATER RAD DEF R600 240V TF70W
$55.73
No image available
W0029565 BEARING HINGE FC TOP TF SL R
$8.18
No image available
W0029567 BEARING HINGE FZR TOP CLOSED
$6.11
No image available
W0029582 SUPPORT SHELF DOUB T&S TF
$10.73
No image available
W0029584 DOOR BIN FZR DIVIDER
No image available
W0029597 PAN DRAIN DYN CON
No image available
W0029599 TWIST&SERVE 2 ICETRAY KIT TOP
No image available
W0029603 REAR HOUSING PCB COVER
$123.60
No image available
W0029604 REAR HOUSING PCB ADAPTER
No image available
W0029607 DRAWER C/COVER TF70 WH ASSY
$51.11
No image available
W0029615 DRAWER CRISP FRONT TF70 WH ASY
No image available
W0029674 HINGE CENTRE BASE ASSY
$28.31
No image available
W0029675 HINGE CENTRE PIN SWING DOOR
No image available
W0029697 COVER FOOT LEFT HINGE GREY
$9.71
No image available
W0029702 HINGE BASE RIGHT ASSY
No image available
W0029708 FOOT LEFT ASSY
$15.08
No image available
W0029740 DRAWER DELI FC HALF WH ASSY
No image available
W0029772 DISPLAY UI WH 1ZONE EXT ASY
$146.25
No image available
W0029830 SUPPORT EVAPORATOR RIGHT TF
$4.65
No image available
W0029842 TUBE CORRUGATE TF
$12.71
No image available
W0029905 EVAPORATOR FF TF70 N
$54.71
No image available
W0029925 CRISPER GASKET 70
$8.55
No image available
W0030202 DOOR PACKED FZR+FC WTB4604SA-R
No image available
W0030344 DOOR BIN FZR TF70 WH HOTF-ART
$38.25
No image available
W0086608 CORD SERVICE INSULATED
No image available
W0147391 COMPRESSOR JIAX TH1116Y
No image available
W0147520 SWITCH DOOR
$19.88
No image available
W0147552 ROLLER REAR WTB4600WA RAYONG
$5.40
No image available
W0147553 SHAFT ROLLER
No image available
W0154010 DOOR BIN FLEX 70 WH-HOTFOIL
No image available
W0154012 DOOR BIN FINGER TF70W WH
No image available
W0154026 LENS COVER BLUE ASSY
$20.63
No image available
W0284102 SEAL FOAM
$6.53
